- základní desky
Bus Type: 4 PCI BUS Sloty (speed 66/100MHz) 3 ISA BUS Sloty 1 AGP Slot
CPU: Intel Pentium® II Processor 233/266/300/333 (66MHz) Intel Pentium® II Processor 350/400/450 (100MHz)
System Memory: 3 168 pin 3.3V unbuffered 100/66MHz DIMM sockets. Podporuje 8 až 384MB 100/66MHz Sync DRAM
BIOS: Award Flash BIOS s PnP ready, podpora 1M nebo 2M
On board IDE: 2 PCI PIO a Bus Master IDE porty, s podporou PIO Mode 4, DMA mode 2 a Ultra DMA 33
I/O Feature: 2 high speed seriové porty (16550 Fast UART kompatibilní) 1 Enhanced paralelní port (SPP/ECP/EPP) 1 Floppy port s podporou 2 floppy mechanik (360K/720K/1.2M/1.44M/2.88M)
Green Function: Podporuje ACPI Power Management, podpora slow down, suspend to memory, suspend to hard disk Advanced LM80 monitoruje 2 ventilátory, 6 power supply voltage, otevření šasi, teplotu mainboardu, podpora interního a externího modemu - ring power on
Podporuje Wakeup on LAN
Podporuje LDCM (volitelné)
Podporuje PS/2 mouse Wakeup, PS/2 keyboard Wakeup (volitelné)
MAXIM 1617 monitoruje teplotu CPU (volitelné)
Infrared wakeup (volitelné)
Board Size: 306 x 190mm
Bus Type: 1 AGP Slot, 3 PCI Sloty, 3 ISA Sloty
CPU: Intel Pentium® II Processors 233/266/300/333MHz Celeron™ 266MHz
System Memory: 2 168pin DIMM sockety, podpora 8 to 256MB SDRAM or 512MB EDO
BIOS: 1M memory, Award Flash BIOS s PnP ready SpeedEasy™, LogoEasy, PowerEasy
On board IDE: 2 PCI PIO a Bus Master IDE porty, s podporou PIO Mode 4, Ultra-DMA/33
I/O Feature: 2 high speed seriové porty (16550 Fast UART kompatibilní)
2 USB konektory
1 Enhanced paralelní port (SPP/ECP/EPP)
1 Floppy port s podporou 2 floppy mechanik (360K/720K/1.2M/1.44M/2.88M)
Green Function: Podpora ACPI a OS Directed Power Management, Advanced Feature ATX power supply support, Provides protection circuit to prevent damage to parallel port Podpora IrDA infrared, Anti-virus function, DMI ready Podpora Windows 95's software power shutdown CPU napájení 1.3v to 3.5v
Podpora KB wakeup, PS/2 mouse wakeup, Infrared wakeup (volitelné)
Podpora interního and externího modemu - ring power on
Podpora wake-up on LAN
Board Size: ATX Form Factor 305 x 175mm
